New Polaris RZR TURBO R 4 ULTIMATE EPS

UNMATCHED CAPABILITY. UNBEATABLE PERFORMANCE.

Delevering thrilling turbo-charged acceleration, maximum manoeuvrability and control, Turbo R 4 is purpose-built with rugged components to withstand the roughest terrain.

THE NEW STANDARD IN WIDE OPEN

You won't approach any off-road challenge the same again. The RZR Turbo R 4 sets the bar for 4-seat performance side-by-sides. It's incredibly responsive, remarkably agile and ruggedly strong.

POWER

A 181-HP turbo-charged engine combined with a wide 74" stance and big 71.12 cm suspension deliver eye-opening acceleration with unbelievable stability so you can tackle big terrain at high-speeds with up to 4 passengers.

STRENGTH

Taking on the most challenging off-road conditions requires extreme durability and the Turbo R 4 delivers with a rigid one-piece chassis with a boxed and stamped-steel suspension.

CONTROL

From the innovative geometry up front to the game-changing 71.12 cm of usable travel in back, the Turbo R 4 has impressive suspension giving you the confidence to chase bigger thrills with family and friends.

POWER

RZR Turbo R 4 is the gateway to a powerful new breed of side-by-side delivering the perfect blend of extreme performance, rugged strength and ultimate stability for confident control with room for four.

181-HP TURBO-CHARGED ENGINE

Get power on-demand from this 181-HP 4-stroke DOHC twin-cylinder turbo-charged machine delivering intense corner-to-corner acceleration.

ELECTRONIC POWER STEERING

Rack-mounted, high assist electronic power steering with quick turn rack delivers confident control in and out of corners and across uneven terrain.

POWER UP YOUR DAY

Accessories are power hungry. Turbo R makes it easy to feed them with a 900 watt stator and the quick-connect Polaris Pulse System.

CONTROL

Exceptional power demands exceptional control. Turbo R delivers with its wide stance, extended wheelbase, rugged suspension and four new, ground-breaking DYNAMIX™ DV ride modes.

ALL-NEW DYNAMIX DV

The industry's most sophisticated suspension controller independently adjusts compression and rebound to keep the Turbo R in contact with the ground on even the most extreme terrain.

REVOLUTIONARY RIDE AND HANDLING MODES

Selectable DYNAMIX ride and handling modes allow you to tune performance on the fly, instantly optimizing shock damping and steering feel for whatever is in your path.

ULTRA-STABLE STANCE

Turbo R's aggressive 74" stance and 317.5 cm wheelbase create a rock solid platform that lets you take full advantage of the 40.64 cm ground clearance and 71.12 cm of usable travel.

STRENGTH

RZR pioneered the sport of side-by-side performance. Nobody's covered more harsh terrain or knows more about building a machine to endure it.

ROBUST SUSPENSION

Equipped with a boxed dual A-Arm with 3-piece stabilizer bar on the front-end and boxed gusseting, toe link, high-clearance radius rods and stabilizer bar in the rear.

ONE-PIECE CHASSIS

Boasts a rigid one-piece chassis and a strengthened driveline so you can push the Turbo R to the extremes repeatedly knowing your ride is up to the test.

UNITIZED HUBS

Unitized hubs protect your bearings from dust, sand and dirt. Your RZR Turbo R 4 will operate at its prime longer, and you'll have the freedom to ride even farther off-road.

A 4-SEATER FOR THOSE WHO WANT NEXT-LEVEL PERFORMANCE

Turbo R 4 Ultimate EPS

Set the standard in the wide-open performance category with an unprecedented combination of power, strength and control plus rider-centric features and the industry's most intelligent suspension.
- 181 HP Turbo-Charged Engine
- 74" Stance and 71.12 cm Useable Travel
- 7” Glove-Touch Display powered by RIDE COMMAND
- Rockford Fosgate
- Front, Rear and Interior Accent Lighting
- DYNAMIX DV with 4 Selectable Ride Modes
- FOX 3.0 Live Valve X2 Internal Bypass Shocks
- Rack Mounted High Assist Electronic Power Steering

Specifications

ENGINE & DRIVETRAIN

Engine type 4-Stroke DOHC Twin Cylinder Turbocharged
Cylinders-Displacement (cc) 925CC / 181 HP
Fuel System Electronic Fuel Injection
Transmission/Final Drive Automatic PVT P/R/N/L/H
Drive System Type Isolated Xtreme Performance True On-Demand AWD/2WD
Cooling Liquid

SUSPENSION / BRAKES / WHEELS

Front shocks FOX 3.0 Live Valve X2 Internal Bypass (Electronically Controlled Compression and Rebound)
Front Suspension Light Weight Boxed Dual A-Arm with 3 Piece Stabilizer Bar and 68.6 cm Usable Travel, 56.5 cm Wheel Travel, Unitized Hubs
Rear shocks FOX 3.0 Live Valve X2 Internal Bypass (Electronically Controlled Compression and Rebound)
Rear Suspension Tubular Trailing Arm with boxed gusseting and Toe Link, High Clearance Radius Rods, and Stabilizer Bar and 71.9cm Usable Travel, 56.9 cm Wheel Travel, Unitized Hubs
Front / Rear Brakes 4-Wheel Hydraulic Disc with Triple-Bore Front and Dual-Bore Rear Callipers; Aluminium Top Hat Rotor
Parking Brake Park in Transmission
Front Tyres 32 x 10-15 Maxxis Rampage Fury; 8-Ply Rated; Wheel Size 15x7
Rear Tyres 32 x 10-15 Maxxis Rampage Fury; 8-Ply Rated; Wheel Size 15x7
Wheels Painted Cast Aluminium Rim with 5-Lug Pattern

DIMENSIONS

Bed Box Dimensions (L x W x H) 66 x 45 x 29.2 cm
Front/Rear Rack or Box Capacity 136 kg
Fuel Capacity 49.2 L
Ground Clearance 40.6 cm
Overall Vehicle Size (L x W x H) 398.8 x 188 x 195.6 cm
Payload capacity 408.2 kg
Wheelbase 317.5 cm
Estimated Dry Weight 1,037 kg

FEATURES

Cargo System Lock & Ride; Fold Flat Rear Storage, convertible rear seat storage with integrated tie down points, 70.4 x 134.1 x 49.53 cm
Doors Front & Rear Full Doors
Electronic Power Steering Rack Mounted High Assist Electronic Power Steering with Quick Turn Rack; Race Inspired Steering Wheel with Tilt and Telescoping Adjustment; DYNAMIX DV with Integrated EPS Modes and Ride Command Push Button Controls
Hitch Towing Rating N/A
Hitch/Type Not Equipped
Instrumentation RIDE COMMAND 7” Glove-Touch Display: Digital Instrumentation, Built-In GPS, Mapping, Vehicle-to-Vehicle with *Group Ride, Follow the Leader, & Messaging. Bluetooth & USB Smartphone Connectivity, AM/FM & Weather Radio, In-Vehicle Communications Capable With Optional Sena Headsets, Rockford Fosgate Premium Audio (Including 2 Tweeters, 2 Front & 2 Rear Speakers, and External 400W Amp) Dual-sweep Analog Dials w/ 4 in LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder Light, Gear Indicator, High Output 900W Charging System, Polaris Pulse System, In-Dash Charge Port, 1 front DC Accy ports, 1 rear DC Accy port, Polaris P.A.S.S., Painted Aluminium Roof, Coloured Toe Link, Mud and Rock Guards
Lighting Signature White LED, Low/High & Red LED Tail / Brake Lights; Front, Rear, and Interior Accent Lighting
Seat Type Cut & Sew Front Bolstered Bucket Seats with 4-way adjustability (including 15.24 cm front to back toolless seat sliders with tilt adjustability) and Retractable Click-6 Harnesses, Rear Stadium style seating with non-retractable 6-point harnesses
Variants Off-road
